Features
- 400 ft-lb Monstrous Power in Ultra-Compact Size (5.2″ Length)
- Brushless Motor Delivers Long Lifespan, Less Maintenance and High Power Ratio
- Electronic Torque Control (ETC) Features Enables 3-Stage Auto-Shutoff (63 / 115 / 178 ft-lb on M20 bolt) + Max (250 ft-lb Tightening)
- Smart Reverse Will Automatically Stop Spinning Once Bolt Is Loosen
- Built-in 3 Super Bright LEDs in Front
Details & Specifications
G12 Series Compact Tools are designed with power & compact size in mind. The family includes a wide range of tools, from drill driver to ratchet wrench and polisher, all share a common slim 12V Li-ion battery platform.
RI12184 Key Features:
– 400 ft-lb Monstrous Power in Ultra-Compact Size (5.2″ Length)
– Brushless Motor Delivers Long Lifespan, Less Maintenance and High Power Ratio
– Electronic Torque Control (ETC) Features Enables 3-Stage Auto-Shutoff (63 / 115 / 178 ft-lb on M20 bolts) + Max (250 ft-lb Tightening)
– Smart Reverse Will Automatically Stop Spinning Once Bolt Is Loosen
– Built-in 3 Super Bright LEDs in Front
– G12 BATTERY PLATFORM – Uses G12 batteries, Compatible with all G12 family tools
Specifications
– Model Number: RI12184
– Voltage: 12 Vdc
– Drive: 1/2″ Square
– Max Reverse Torque * : 400 ft-lbs. (540 Nm)
– Max Tightening Torque *: 250 ftlbs (337 Nm)
– Torque Control (Tightening) * : ETC 3-Stage Auto-Shutoff (63/115/178 ft-lb) + Max 250 ft-lbs
– Torque Control (Reverse): Smart Reverse (Stop Spinning When Bolt Loosen)
– No Load Speed: 0-2,800 RPM
– Impact Per Minute: 0-3,200 IPM
– LED Light: Yes (3-LEDs)
– Tool Weight: 2.20 lbs. (2.6 kg)
* All Torque measurement based on hard joint with M20 test bolts in lab condition
– Battery & Charger : G12 battery, Check Tool Kit Packing Config.
Includes:
Li-ion Battery Pack x2
Intelligent Charger x1
Other Attributes
- EAN#:
- SKU#: RI12184-xx
- Shipping Weight (lbs): Approx. 0.0
- Application: Fastening
- Tool Grade / Type: Compact Impact Wrench
- Number of Tool: 1
- Power Sources: 12V Battery Li-ion
- Battery Platform: G12
- Drive Size: 1/2″
- Motor Technologies:
- Max Torque (Ft-Lbs): 90,
- Max RPM: 2400
- Max IPM: 3100
- Wireless Comm.:
- Angle Measurement:
- Case Qty: 5
- Country of Origin: Taiwan
