Pro-Assembly series is designed to precision assembly process on work floor. With precision torque setting, auto shut-off features, and wireless features & mobile app (depends on models), the Pro-Assembly series is the best choice for professional manufacturing.
Features
* 1/2″ Square drive, 50-stage Pre-set Torque from 25 to 180 Nm (18.5 to 132.8 ft-lbs)
* Electronic Torque Control & Auto-shut-off
* LED & Buzzer indicator confirms joint status for OK (green) or NG (red)
* Display showing torque stage & error message
* Max. 375 Nm reverse torque
* P20 battery platform with LED battery level indicator
* USB port for uploading program & downloading data
Specifications
* Drive Size: 1/2″ Square
* micro-USB port
* Voltage: 20V
* Battery: P20 platform
* Max Reverse Torque: 375 Nm (277 ft-lbs)
* Max Tightening Torque: 250 Nm (185 ft-lbs) (M16)
* Torque Setting Range: 25 to 180 Nm (18.5 to 132.8 ft-lbs)
* No Load Speed: 0 to 2,600 RPM
* Impacts Per Minute: 0 to 3,000 IPM
* Net Weight: 1.66 kg (3.65 lbs)
* Dimensions: 202 mm x 68 mm x 252 mm (8.0″ x 2.7″ x 9.9″)
